プロジェクト概要
The 50 ton battery omnidirectional transfer cart is a heavy-duty electric transport equipment designed for large and complex industrial handling tasks. The customer, Oil and Gas Equipment Industries, is based in Saudi Arabia and specializes in oil and gas energy products and services. They have long faced challenges in handling, lifting, and transporting large storage tanks for oil and natural gas, as these tanks are extremely large in volume and weight, and their tank walls are relatively thin with no suitable lifting points. Traditional lifting and handling methods could easily cause damage to the tank walls.
について 50 ton battery omnidirectional transfer cart we designed and manufactured for them perfectly addresses their handling needs, enabling efficient and safe transportation of large oil and gas storage tanks.
顧客ニーズ
Customer challenge: Heavy transport
The customer’s challenge was that these tanks for storing oil and natural gas were very large and heavy, making them difficult to move, especially when transferring them inside and outside the workshop. The space was limited, and the workshop environment was complex. Traditional transport methods were no longer safe or efficient for transporting these tanks. There were also some blind spots that cranes could not reach, which further increased the handling difficulty for large storage tanks.
ソリューション
REMARKABLE proposed a heavy-load 50 ton battery omnidirectional transfer cart solution with a multi-drive system to meet the customer’s requirements.
The trolley is size 8000 × 3000 × 800 mm and can transport tanks ranging from 4000 to 13000 mm in size. With a 50-ton load capacity, the 50 ton battery omnidirectional transfer cart handles cargo weighing between 1 to 50 tons. Additionally, we equipped the omnidirectional transfer cart with a lifting mechanism, providing a 300 mm lift height.
The customer places the storage tank on a pallet for production operations. When transferring to another production process, the 50 ton battery omnidirectional transfer cart maneuvers underneath the pallet, lifts the entire pallet with the storage tank, and transports it safely to the designated location.
Product Specifications
| Trolley Dimensions | 8000 × 3000 × 800 mm (L × W × H) |
| Cargo Type | Storage Tanks |
| Cargo Size Range | 4000 to 13000 mm |
| Cargo Weight Range | 1 to 50 tons |
| 負荷容量 | 50 tons |
| Lift Height | 300 mm |
| Movement System | |
| Drive | Servo motors |
| Design | Steering-wheel omnidirectional movement |
| Wheel Capability | Each wheel set steers/moves synchronously in any direction on the spot |
| Maneuverability | Zero turning radius 360° in-place rotation Highly suitable for limited-space workshops |
| Application Process | 1. Customer places the storage tank on a pallet 2 . Cart maneuvers underneath the pallet 3. Cart lifts pallet + tank 4. Cart transports to the designated location |
| Key Advantages | Boost Operational Efficiency Ensure Safety & Stability Reduce Costs & Labor Achieve Precision & Flexibility |
ライブビデオ・デモ：
結論
The heavy-duty self-propelled electric transfer trolley, represented by the 50 ton battery omnidirectional transfer cart, is a mature and continuously innovative transport solution developed by リマーカブル. We have numerous successful cases both domestically and internationally, serving industries such as energy storage, oil & gas, steel, automotive manufacturing, papermaking, military & aerospace, and furniture, with customized transport solutions and electric transfer carts.
Moreover, the self-propelled trackless transfer cart can be upgraded to an 無人搬送車 (AGV), allowing the 50 ton battery omnidirectional transfer cart to integrate seamlessly into automated production lines and smart workshops, meeting the evolving needs of industrial automation.
